marketed in 1979
super 8 mm film
lens: Zoom f: 1.3 \ F:
15-25 mm
lamp: 100 W, 12 V, EFP
reel capacity: 180 m
projection: forward,
reverse
projection speed: 18, 24
fps, by selector switch
film loading: fully
automatic reel to reel threading
sound: magnetic playback
on both sound tracks
sound mode: mono, duo
amplifier: transistorized
amplifier output: ?
frequency response: ?
recording: magnetic
recording on main track
recording level control:
ALL system (Auto Level Limiter) and manual
sound-on-sound system:
adjustable level control, fade-in/fade-out
sound mixing: imultaneous
recording from Mic and Aux-in terminals possible
VU meter: record level
meter
input terminal: Microphone,
Line-in
input jacks: Mic: 3.5 mm
diameter jack; Aux: 5-pin DIN plug (Eurepean type) and 3.5 mm diameter
jack
output terminal: Monitor,
Line-out, Dubbing-out, Ext Speaker (4-8 Ohm)
output jacks: Mon: 3.5 mm
diameter jack; Line: 5-pin DIN plug (Eurepean type); Dub: 2 x 3.5 mm
diameter jacks (R&L); Ext Sp: 2-pin DIN plug and 3.5 mm diameter jack
built-in speaker: 10 cm
diameter round speaker, 2 W (8 Ohm)
built-in film cutter: yes
motor: electronically
governed DC magnetic motor
power source: ? V AC,
50/60 Hz
weight: circa 8,000 g
dimensions: 175 x 250 x
337 mm
made in Japan by Yamawa
