marketed in 1978
super 8 mm film
lens: Isco-Göttingen Vario-Kiptagon f: 1.4 \ F: 14 mm (1)
lamp: 100 W, 12 V, EFP
lamp settings: High, Low
screen: 224 x 300 mm
diagonal: 360 mm
reel capacity: 180 m
projection: forward, reverse
projection speed: 18, 24 fps
film counter: 4 digits
film loading: automatic threading
sound: magnetic playback on both sound tracks
sound mode: mono, duo (2)
track selection: 1, 2, 1+2
track transfer: 1 to 2, 2 to 1
amplifier: transistorized, 1 IC
amplifier output: music power 15 W
frequency response: 75-10,000 Hz at 18 fps, 75-12,000 Hz at 24 fps
recording: magnetic recording on main sound track
sound-on-sound: and sound fading
recording level control: auto (High, Low)
sound mixing: available
input terminal: Microphone (0.35 mV, 4.7 kOhm), Phono (100 mV, 470 kOhm), Line-in (500 mV, 15 kOhm)
input jack: 5-pin DIN plug (European type)
output terminal: Line-out (?), External Speaker (4 Ohm)
output jacks: Ext Sp: 2-pin DIN plug; Line-out: 5-pin DIN plug (European type)
built-in speaker: yes
synchronized sound socket: double-system, synchronized sound with a tape recorder
motor: magnetic motor
power source: 110-120/130-220-240 V AC, 50 Hz, 200 W, 1.6 Amp
weight: circa 16,800 g
dimensions: 305 (H) x 355 (W) x 470 (L) mm (wuth arm folded)
made in Italy by Silma
(1) possible normal projection with this fixed focal lens: 86 x 115 cm at 3 m. Optional lens: Will-Wetzlar Vario-Travenon 1.3 \ 16.5-30 mm:
- with 16.5 mm zoom, 73 x 97 cm at 3 m,
- with 30 mm zoom 40 x 54 cm at 3 m.
(2) Projector with Duo Play System, which allowed the voice to be put on the first track and background music on the other.
