marketed in 1978
super 8 mm film
lens: Bolex Hi-Fi f: 1.3 \ F:
15-30 mm
lamp: 100 W, 12 V, EFP
reel capacity: 180 m
projection: forward, reverse
projection speed: 18, 24 fps
film counter: yes
film loading: fully automatic
reel to reel threading
sound: magnetic playback
on both sound tracks
sound mode:
mono, duo
amplifier: 1
operational amplifier, 25 Transistors, 4 Diodes, 1 Bridge Rectifier, 5
Light-Emitting Diodes
amplifier output: 10
W sinusoidal, 15 W musical
signal/background
noise ratio: +/- 43 dB
frequency
response: 75-10,000 Hz at 18 fps, 75-12,000 Hz at 24 fps
public-adress: yes
(1)
recording: magnetic recording on
both sound tracks,
fading sound, sound-on-sound
recording level control: ALL
(Auto Level Limiter) and manual (2)
magnetic heads:
a single unit comprising the recording/playback heads and erasing heads
(3)
sound/picture
separation: 18 frames in accordance with super 8 standards
recording level
indicator: digital with Light-Emitting diodes
mixing: possible
input terminal: Microphone
(0.3-100 mV, 9 kOhms), Phono (50 mV- 3 V, 470 kOhm)
input jacks: 5-pin
DIN
output terminal: External
Speaker (4-6 Ohm), Line-out
output jacks: Ext Sp:2-pin DIN;
Line: 5-pin DIN
built-in speaker: sinus 10 W
motor:
asynchronous magnetic motor drive
power source:
available in two versions:
-
220-230-240-250
AC, 50 Hz
-
100-110-117-125-200-220-240 AC, 50/60 Hz
weight: circa
6,000 g
dimensions: 221
x 206 x 335 mm
made in Austria by Eumig
