marketed in March 1977
super 8 mm film
aperture size: 4
x 5.4 mm
lens: Canon PS f: 1.3 mm \ F:
17-28 mm
lamp: 80 W, 30 V, ELB
pilot lamp: yes
reel capacity: 120 m (400 ft)
projection: forward, not
reverse, still
projection speed: 18,
24 fps
film loading: automatic
threading
rewinding: approx 100 sec
sound: single-system, magnetic
recording on main sound track
sound mode: mono
sound control: volume, tone
amplifier:
transistorized
amplifier output: 2.5 W
frequency
response: ?
recording: magnetic recording
on main sound track
sound-on-sound: sound-on-sound,sound
fading
recording system: volume level
control (ALC)
input terminal: Microphone,
Auxiliary
input
jacks: Microphone: 3.5 mm mini-jack, Auxiliary:
DIN 5-pin plug (Eurepean type)
output terminal: Monitor (8 Ohm),
Auxiliary, External Speaker (8 ohm)
output jacks:
Auxiliary: DIN 5-pin
plug (Eurepean type), Ext Sp: DIN 2-pin plug, Monitor: 3.5 mm mini-jack
built-in speaker: 10 cm
diameter round speaker
built-in film cutter: yes
motor: magnetic motor
power source: 100-240 V AC, 50/60 Hz,
140
W
weight: 6,100 g
dimensions: 180 x 290 x 300 mm
made in Japan by Canon
