marketed in 197?
super 8 mm film
lens: Chinon Lens f: 1.3 \ F: 19 mm
lamp:
-
150 W, 120 V, DNE (for Usa
and Canada)
-
100 W, 12 V, EFP (for other
countries)
pilot lamp: built-in on main
switch, 4 V-0.75 A (KE-030)
reel capacity: 180 m
film loading: automatic threading
projection: forward,
reverse
projection speed: 18, 24
fps
sound: magnetic playback on
main sound track
sound mode: mono
sound controls: volume, tone
amplifier: transistorized; 2 IC,
4 transistors, 12 diodes, 1 LED
amplifier output: 2 W/8 Ohm max
public address system: yes
recording: magnetic recording
on main sound track, sound-on-sound,
fading sound
recording level control: auto
input terminal: Public Address, Microphone,
Auxiliary
input jacks: Microphone: 3.5 mm
mini jack; Auxiliary: RCA plug (for Canada and Usa) and 5-pin DIN jack (for other countries)
output terminal: External Speaker
(8 Ohm)
output jacks: Ext Sp: RCA plug
(for Canada and Usa) and 2-pin DIN jack (for other countries)
built-in speaker: 10 cm
diameter round speaker, 2 W (8 Ohm)
motor: magnetic motor
power source:
-
120 V AC, 50/60 Hz,
230 W (for Usa and Canada)
-
200-230-250 V AC, 50/60 Hz, 120
W (for other countries)
weight: 7000 g
dimensions: 180 (W) x 245 (H) x 340
(L) mm
made in Japan by Chinon
