marketed in 1980-81
super 8 mm film
lens: Elmo f: 1.2 \ F: 25-50 mm or Elmo f: 1.0 \ F: 12.5-30
lamp: 250 W xenon-arc lamp
lamp settings: Low, High
reel capacity: 360 m (1200 ft)
angle adjustment: up to 7º (inclination adjustment is possible)
projection: forward, reverse
projection speed: 18, 24 fps (fine adjustable speed)
slow projection: possible
film rewinding: hig speed rewind
frame counter: 4 digits
film loading: automatic threading
manual unloading: possible
remote control: forward and reverse projection and switch-over of magnetic recording and reproduction can be remotely controlled with an optional remote control unit
sound: optical playback on main sound track and magnetic playback on both sound tracks
sound mode: optical (mono), magnetic (mono, duo, stereo)
amplifier output: 2 x 30 W/8 Ohm
frequency response: 50-13500 Hz at 24 fps
optic sound light: 4 V/0.75 Amp (KE-02/BRS type), DC lighting system
volume control: individual volume control of track 1 and track 2
tone control: bass and treble separate control for both track 1 and track 2
recording: magnetic recording on both sound tracks, sound fading, sound-on-sound
recording level control: automatic (ALC) and manual
VU meter: 2 (R&L), recording level meter
sound mixing: sound from AUX-IN jack and MIC jack can be mixed
stereo recording/reproduction: smultaneous magnetic recording/reproduction of sound on track 1 and track 2 for true stereo sound is possible
2-track recording/reproduction: simultaneous and individual recording/reproduction of sound on track 1 and/or track 2 is possible
spot recording: possible simultaneously or independently on track 1 and track 2
double recording: possible simultaneously or independently on track 1 and track 2
track-to-track sound transfer: possible from track 1 to track 2 or vice versa
input terminals: 2 (L&R) x Microphone (500 Ohm-100 kOhm, -72 dBs), 2 (L%R) x Auxiliary-in (5o kOhm, -20 dBs), Public Address
input jacks: mini jack
output terminal: 2 (L&R) x Auxiliary, 2 (L&R) x External Speaker (8 Ohm), 2 (L&R) x Monitor (8-16 Ohm)
output jacks: Aux: mini jack; Ext Sp: 2-pin DIN; Mon mini jack & normal jack
built-in speaker: 2 (L&R) x 12.5 cm diameter dynamic speakers bulit-in
synchronized sound socket: sound synchronization with tape recorder
remote control socket: yes
built-in cutter: yes
motor: 4 motors used: main electronic governor DC motor, take-up motor, rewind motor and cooling fan motor
power source: 110 to 240 V AC, 50/60 Hz
power consumption: 450 W
weight: 16,5000 g
dimensions: 219 x 299 x 385 mm
made in Japan by Elmo
