marketed in 197?
super 8 mm film
lens: Elmo Super Zoom f: 1.3 \
F: 15-25 mm
lamp: 100 W, 12 V, EFP
reel capacity: 180 m
frame counter: no
projection: forward, reverse
projection speed: 18, 24 fps
film loading: automatic
threading
manual unloading: possible
sound: magnetic playback on
both sound tracks
sound mode: mono, duoplay
(1)
amplifier: transistorized with
2 IC's, 3 transistors, 8 diodes
amplifier output: 6
W (8 Ohm)
frequency response: ?
sound control: volume, sound
track selector
recording: magnetic recording
on both sound tracks
recording level control:
automatic
sound-on-sound: yes
VU meter: recording level
meter
erasing head: ferrite
magnetic head
input terminal: Microphone (500
Ohm-10 kOhm),
Auxiliar-in (10 kOhm)
output terminal:
Monitor/Auxiliar-out (16 Ohm), External Speaker (8 Ohm)
terminal jacks: Mic, Aux and
Mon: 3.5 mm mini-jack; Ex Sp: DIN 2-pin plug
built-in speaker: 12.5 cm
diameter round speaker
built-in cutter: yes
motor: frequency generator sevo DC magnetic motor
power source:
100-115-125-220-230-240 V AC, 50/60 Hz,
200 W
weight: ?
dimensions: 180 (W) x 270 (H) x
315 (L) (with arms folded)
made in Japan by Elmo
