marketed in 1979
super 8 mm film
lens: Eumig Vario-Eupronet Multicoated f: 1.3 \ F: 15-30 mm
lamp: 100 W, 12 V, EFP
light settings: Low, High
reel capacity: 180 m
projection: forward, reverse
projection speed: 18, 24 fps
film loading: automatic threading
sound: magnetic playback on both sound tracks
sound-picture distance: 18 frames
sound mode: mono, duo
sound controls: volume, tone, tric, recording level
soundstripe control: 1, 2, 1+2
amplifier: 1 IC, 18 transistors, 3 diodes
amplifier output: sinus 10 W, music power 15 W
frequency response: 75-10000 Hz at 18 fps, 75-12000 Hz at 24 fps
wow and flucter: +/- 0.4 % (DIN 45 507)
VU meter: yes
recording: magnetic recordingon both tracks, fading sound, sound-on sound
recording level control: ALL (Auto Level Limiter) and manual
mixing: possible
input terminal: Microphone (0.3-100 mV, 9 kOhm), Phone (50 mV-3V, 470 kOhm)
input jacks: 5-pin European DIN
output terminal: External Speaker (4-6 Ohm), Monitor, Line-out
output jacks: Line-out: 5-pin European DIN; Ext Sp: 2-pin DIN; Mon: 3.5 mm mini jack
built-in speaker: yes
motor: synchronous magnetic motor
power source: V AC, 50/60 Hz
weight: 8500 g
dimensions: 206 x 256 x 333
made in Austria by Eumig
