marketed in 1977-78
standard 8 mm / super 8 mm film
film format change: auto, by
lever
lens: Will Wetzlar Vario
Travenon f: 1.3 \ F:
16.5-30 mm
lamp: 100 W, 12 V, EFN
reel capacity: 240 m
film loading: automatic
threading
projection: forward,
reverse
projection speed: 18, 24
fps
film counter: yes
sound: magnetic playback on
both sound tracks
sound mode: mono, duo
sound controls: volume, tone,
treble, trick, R track volume, L track volume
amplifier: transistorized
amplifier output: music power
20 W
frequency response: 80-8,000
at 18 fps, 80-10,000 Hz at 24 fps, +5 dB
recording: magnetic recording on
both sound
tracks, sound-on-sound, sound fading
recording level control: auto
and manual
input terminal: Microphone
(1-10 mV, 3-600 Ohm),
Phono (50-1000 mV, 470 kOhm)
input jacks: 5-pin
DIN (European type)
output terminal: External Speaker (4-8 Ohm)
output jacks: Ext Sp: 2-pin DIN
built-in speaker: yes
motor: magnetic motor
power source: 220 V AC, 50/60 Hz
weight: 9500 g
dimensions: 180 x 330 x 340 mm
made in Italy by Silma
