marketed in 197?
article num: 82??
super 8 mm film
lens: Revuenon f: 1.3 \ F: 15-30 mm
lamp: 150 W, 15 V, EFR
bright settings: High, Low
reel capacity: 180 m
film loading: automatic threading
projection: forward,
reverse
projection speed: 18, 24
fps, with speed adjustment +/- 1.5 fps
frame counter: yes
sound: magnetic and optical playback,
2 sound tracks
sound mode: mono, duo
amplifier: tranistorized; 8 ICs,
15 transistors, 17 diodes, 4 LEDs
amplifier output: ?
frequency response: ?
VU meter: 1
exciter lamp: 4 V DC, 0.75
A
track sound controls: balance,
tone, volume, recording level, sound-on-sound
recording: magnetic on both
tracks, sound-on-sound,
fading sound
recording level control: auto
and manual
input terminal: Microphone,
Auxiliary (-300 mV, 1 MOhm)
output terminal: Headphones,
Auxiliary, External Speaker
built-in speaker: yes
built-in monitor screen: yes
motor: magnetic motor
power source:
110-120-127-220-240-250 V AC, 50/60 Hz, 230 W
weight: 9500 g
dimensions: 180 x 245 x 340 mm
made in Japan [by Chinon]
