marketed in 197?
article num: 8240
super 8 mm film
lens: Revuenon Zoom f: 1.3 \ F: 15.5-30 mm
lamp: 100 W, 12 V, EFP
reel capacity: 180 m
film loading: automatic threading
projection: forward,
reverse
projection speed: 18, 24
fps, with variable speed control dial
sound: magnetic playback on
mains sound track
sound mode: mono
amplifier: transistorized
amplifier output: 5W /6W (4 Ohm)
sinus/max; 2.5W /3W (8 Ohm) sinus/max
frequency response: ?
sound controls: volume, tone
recording: magnetic recording
on main sound track
input terminal: Microphone (0.5
mV, 1.2 kOhm),
Phone (300mV, 470 kOhm)
output terminal: Monitor,
External Speaker (4-8 Ohm)
input jacks:
Microphone: 3.5 mm mini jack, Phono: DIN 5-pin plug
output jacks:
Monitor: 3.5 mm mini-jack, Ext Sp: DIN 2-pin plug
built-in speaker: yes
motor: DC magnetic motor
power source: 100-250 V AC, 50/60 Hz,
180 W
weight: 8200g
dimensions: 145 x 245 x 320
made in Japan by Chinon
