marketed in 197?
article num: 82??
super 8 mm film
lens: Revuenon Zoom f: 1.3 \ F: 15-30 mm
lamp: 100 W, 12 V, EFP
reel capacity: 180 m
film loading: automatic threading
projection: forward,
reverse
projection speed: 18, 24
fps, with variable speed control dial
sound: magnetic playback on
main sound track
sound mode: mono
amplifier:
transistorized
amplifier
output: 4 W
frequency
response: 75-10,000 Hz at 18 fps
recording: magnetic recording
on main track,
sound-on-sound
recording level
control: auto
recording level
meter: yes
input terminal:
Microphone (0.3-100 mV, 9 kOhm)), Phono (50 mV-3 V, 470 kOhm)
input jack:
DIN 5-pin plug (Eurepean type)
output terminal: Monitor,
Auxiliary, External Speaker
outpu
jack: Monitor: mini jack, Aux: DIN 5-pin plug (Eurepean type), Ext
Sp: DIN 2-pin plug
built-in speaker: yes
motor:
asynchronous magnetic motor
power source:
220 V AC, 50/60 Hz, 185 W
weight: 8200 g
dimensions: 200
x 230 x 295 mm
made in Germany by Eumig
